Split a Relationship with an Element

You may place a new element on a relationship. It will cause splitting the relationship into two parts which will be connected to the original start and end element on one side and to the new element on the other side.

If you want to incorporate a new element into an existing flow, you do not need to unconnect and reconnect the existing relationships. You may simply drop a new element over an existing relationship to insert it there. The relationship will be automatically splitted in two and correctly connected as you would expect it.

Splitting a Relationship with an Element
Splitting a Relationship with an Element
